The Pre-Loader Machine is an automatic corrugated board transport system engineered to meet stringent standards for reliability, durability, and operational safety. Constructed with premium-grade components and precision manufacturing, it enables fully autonomous sheet feeding with an overlapping flow pattern for seamless stacking and conveyance.
Dual-Sided Alignment Mechanism: Integrated into the buffer zone to ensure stable material positioning.
Auto-Adjusting Height Function: Front-guided alignment for fluted board, adapting to varying sheet thicknesses.
Production Synchronization: Real-time speed coordination with folder gluer stitcher/printing equipment to maintain consistent output.
Designed for industrial efficiency, the system minimizes manual intervention while optimizing production line stability.
|
Model |
1225 |
1425 |
1628 |
1636 |
|
Work type |
Pre feeder For Flip Flop(Top Printer)/ No Flip (Bottom Printer) |
|||
|
Max.sheet size(mm) |
1200*2500 |
1400*2500 |
1600*2800 |
1600*3600 |
|
Min.sheet size(mm) |
350*600 |
350*600 |
350*700 |
400*700 |
|
Max.stacking height(mm) |
1800 |
1800 |
1800 |
1800 |
|
Max.speed(pcs/min) |
250(3 ply) |
200(3 ply) |
200(3 ply) |
160(3 ply) |
|
Center Alignment(mm) |
±150 |
±150 |
±150 |
±150 |
|
Machine weight(kg) |
6000 |
7500 |
7500 |
7500 |
|
Total power(kw) |
23 |
23 |
23 |
23 |
|
Air Source(kg/cm²) |
6 |
6 |
6 |
6 |
|
Ambient temperature |
-5℃-45℃,relative humidity 95℃ RH |
|||
|
Power supply |
380V±10%, 50HZ±1HZ, 3PHASE |
|||
Note: When the customer has special requirements for customization and affects the parameters in this table, the accrual value shall prevail.
