graphite electrode HP550mm

3 month ago

13 0

Hebei Shitu New Materials Technology Co., LTD

 3 month year

Product details

1、Will the dust collection system on the electric arc furnace have any impact on the usage and consumption of electrodes?

The fan used in the dust collection system generates a certain negative pressure during operation. During steelmaking, this increases the air flow rate around the red-hot electrode, thereby also increasing the oxidation consumption of the electrode. During steelmaking, a well-regulated dust collection system not only maintains a good working environment but also stabilizes the consumption of the electrode.

2. How can we avoid an increase in electrode consumption during steelmaking?

To avoid increased electrode consumption during steelmaking, the following measures should be taken: (1) Maintain a good power supply state and supply power within the allowable current intensity range of the electrode as per the design requirements of the electric furnace. (2) Prevent the arc starting point from being immersed in the molten pool. (3) Prevent the electrode from being immersed in molten steel to increase carbon deposits. (4) If conditions permit, the electrode adopts spray cooling technology. (5) Set up the correct exhaust gas emission system. (6) Adopt the correct oxygen-blowing system.

3. How long does the production cycle of graphite electrodes take?

The production process and corresponding time for a batch of ultra-high power or high power graphite electrodes are as follows: electrode pressing (3 days)- calcination (25 days)- impregnation (4 days)- re-calcination (15 days)- graphitization (10 days)- machining and quality inspection (2 days)- finished product packaging and shipment (1 day), that is, from material input to product shipment The fastest production cycle without interruption is 60 days. However, for the production of electrode connectors, which requires two more immersion and three more baking processes than electrodes, the fastest production cycle is also 90 days.

4、What are the characteristics of the electrodes produced by the serial-connected graphitization furnace?

The development direction of graphitization furnaces is the internal heat serial-connected graphitization furnace. Since the current density of the series-connected columns is the same, the difference in electrode resistivity is very small. Secondly, the resistivity at both ends of the inner series graphitization products should be slightly lower than that in the middle (the resistivity at both ends of the graphitization products of the Etchison furnace is higher than that in the middle), which is conducive to reducing the resistance at the connection point during user operation and alleviating the overheating and redness phenomenon at the connection point of the joint. Therefore, the electrode quality uniformity produced by the series graphitization furnace is better than that of the Etchison furnace and is more suitable for the production requirements of electric arc furnace steelmaking.

5.Different power electric furnaces should use graphite electrodes of different powers. graphite electrodes are classified by grade into (regular power)RP graphite electrode,( 68337902,high power)HP graphite electrode, and (ultra high power)UHP graphite electrode.
