Wear Resistant Food Contact Grade MC Nylon Sheet

MC Nylon (Monomer Casting Nylon) sheet is a polyamide 6 engineering plastic sheet made by anionic polymerization process, with high molecular weight (about 100,000) and high crystallinity. Compared with ordinary extruded nylon, its mechanical properties are improved by more than 30%, and it is a high-performance solution to replace metals, thermosetting plastics and ordinary engineering plastics.

Performance parameters

Physical and mechanical properties

Density: 1.15-1.16 g/cm³

Tensile strength: 80-95 MPa

Flexural strength: 110-130 MPa

Compressive strength: 90-110 MPa

Impact strength (unnotched): 120-150 kJ/m²

Rockwell hardness: M85-M95

Friction coefficient (dry friction): 0.15-0.25 (vs. steel)

Thermal properties

Melting point: 215-225℃

Heat deformation temperature (1.82MPa): 160-180℃

Continuous use temperature: -40℃~+120℃

Linear expansion coefficient: 8×10⁻⁵/℃

Chemical stability

Excellent oil resistance (mineral oil, hydraulic oil)

Resistant to alcohols and aliphatic hydrocarbons, not resistant to strong acids/phenols

Hydrolysis resistance is better than ordinary PA6 (can be exposed to water for a short period of time)

Electrical properties

Volume resistivity: 10¹³ Ω·cm

Dielectric strength: 30 kV/mm

mc 901

Core advantages of the mc nylon sheet

Ultra-high mechanical strength

The tensile/bending strength is 30% higher than that of ordinary PA6, close to the specific strength of metal aluminum, with excellent impact resistance, suitable for dynamic load parts.

Excellent wear resistance

The wear amount is only 1/3 of that of ordinary nylon, with self-lubricating properties, and can run without oil lubrication.

Dimensional stability

The water absorption rate (saturated) is <3%, which is lower than that of extruded nylon (6-8%), with small deformation after processing, and the precision can reach IT8 level.

Chemical corrosion resistance

Can withstand acid and alkali (pH 3-11), oil and seawater corrosion.

Noise reduction and shock absorption

Elastic modulus 2.8-3.2 GPa, effectively absorbs mechanical vibration.

Processing convenience

It can be used for metal processing such as turning, milling, drilling, and grinding, without the need for special equipment, and the processing efficiency is 50% higher than PTFE.

casting nylon
