Manufactured in China Pneumatic Device for Separating Ceramics From Castings1

3 month ago

14 0

Shandong Enon Automation Technology Co., Ltd.

 4 month year

Product details

1,Technical parameters

Illustrate	Unit	YN-ZKJ-0.6L
Impact energy	J	≥120
Impact frequency	HZ	≥46
Air consumption	L/S	≤54
working pressure	MPa	≥0.5
Can be installed in the shell space	mm	500X450
Maximum height of pickaxe	mm	600
Vibrating rod lifting height	mm	300
Table size	mm	600×800
Dimensions	mm	850×600×2400

2,Main structural features:

^{(1) Main structural features}

^{1. This machine uses a CB-47 crusher to provide impact energy, and the impact operation is pneumatically controlled.
2. The YN-ZKJ-0.6L type workbench is 0°, and the vibration is relatively stable.
3. The whole machine is welded with section steel and hot-rolled steel plates to ensure high strength and low vibration and noise.
4. No electricity configuration, pneumatic operation, safer and more convenient for outdoor use. The vibration starts automatically when operated on the right side, and the equipment comes with a complete gas distribution system.}
(2) Configuration instructions
^{1. The main machine is welded with high-quality 120# channel steel and δ12 hot-rolled steel plate.
2. The cylinder and pneumatic components are all made of MC, rock drill type CB-47 3. The piston and sealing materials are from Freudenberg, Germany.}
