| Standard | ASTM B241 |
| Grades | Al 1060 Al 1100 Al 2014 Al 2024，etc. |
| Fin Type | Solid |
| Manufacturing Process | High-Frequency Resistance Welding |
| Surface Finish | Mill Finish / Anodized / Anti-Corrosion Coating |
| Tube OD | 16 mm – 73 mm |
| Tube WT | 1.0 mm – 4.0 mm |
| Fin Height | 6 mm – 20 mm |
| Fin Thickness | 0.8 mm – 1.2 mm |
| Fin Pitch | 2.0 mm – 6.0 mm |
| Tube Length | customized |
| Grade | Si (%) | Fe (%) | Cu (%) | Mn (%) | Mg (%) | Zn (%) | Ti (%) | Al (%) |
|---|---|---|---|---|---|---|---|---|
| Al 1060 | ≤0.25 | ≤0.35 | ≤0.05 | ≤0.03 | ≤0.03 | ≤0.05 | ≤0.03 | ≥99.6 |
| Al 5052 | 0.25 | 0.40 | ≤0.10 | 0.10 | 2.2–2.8 | ≤0.10 | ≤0.15 | Balance |
| Al 6063 | 0.20–0.60 | ≤0.35 | ≤0.10 | ≤0.10 | 0.45–0.90 | ≤0.10 | ≤0.10 | Balance |
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Thermal Conductivity (W/m·K) | Density (g/cm³) |
|---|---|---|---|---|---|
| Al 1060 | ≥60 | ≥30 | ≥25 | 234 | 2.70 |
| Al 5052 | ≥215 | ≥130 | ≥10 | 138 | 2.68 |
| Al 6063 | ≥160 | ≥110 | ≥12 | 201 | 2.70 |
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
