FEATURES AT A GLANCE
Big shuttle hook /bobbin case /bobbin
Fold layer : 1-5 layers
Width : as per products make
high speed
Auto-fold
Auto-sewing
Easy operation
PRODUCT SPECIFICATIONS
|
No |
Item |
Data |
|
1 |
Sewing area |
250*160mm |
|
2 |
Stitches type |
lockstitch |
|
3 |
Stitch length |
1-2mm |
|
4 |
Max. thickness |
1-10mm |
|
5 |
Max. speed |
2800rpm/min |
|
6 |
Max .stitches |
10000 stitches/design |
|
7 |
Max.number of designs |
Store 1000 fuselage design, external usb design for unlimited |
|
8 |
Max. folding layers |
five |
|
9 |
Shuttle hook |
three times big hook |
|
10 |
Needle type |
DP*17 18-25# |
|
11 |
Needle cooling system |
yes |
|
12 |
Lifting height of internal presser foot |
28mm |
|
13 |
Presser foot form of middle presser foot |
motor |
|
14 |
Stepping foot stroke |
4-10mm |
|
15 |
Work holder lift height |
30mm |
|
16 |
Voltage |
220v 750 W |
|
17 |
Dimensions (with packaging) |
1260MM*1300MM*1450MM |
|
18 |
Weight /Package |
260kg |
|
19 |
PACKAGE |
wooden case |
If you are interested in the product, contact 2bvideo.com for more information for more information
