Product details

DCV20 Manual Single-spool Directional Control Valve

The DCV20 manual single-spool directional control valve is a high-performance hydraulic valve designed for a wide range of industrial applications. With a rated flow rate of 20 liters/minute and a maximum pressure of 350 bar, this valve provides precise and reliable flow control for various hydraulic systems. Its compact, monoblock design ensures durability and space efficiency, making it suitable for applications with limited space.

Parameter	Specification
Control Method	Manual, Joystick, Manual + Joystick
Spool Configuration	1 Spool, 2 Spools, 3 Spools, 4 Spools, 5 Spools, 6 Spools
Nominal Flow	20 L/min (5.2 US gpm)
Max Working Pressure	350 bar (5100 psi)
Inlet Port	G3/8, M18×1.5, SAE 8, 3/8 NPT
Outlet Port	G3/8, M18×1.5, SAE 8, 3/8 NPT
Port Size	G3/8, M18×1.5, SAE 8, 3/8 NPT
Section Configuration	1st Section, 2nd Section, 3rd Section, 4th Section, 5th Section, 6th Section
Structure Type	Monoblock Valve
Ambient Temperature Range	-40°C to +80°C (-40°F to +176°F)
Operating Viscosity Range	15 - 75 mm²/s (15 cSt to 75 cSt)

Customization and OEM Services: We offer customization and OEM services to tailor valves to your specific requirements. Our experienced engineers will work closely with you to design and manufacture valves that meet your exact specifications and performance needs.

Quality Assurance: All our products undergo rigorous testing and quality control procedures to ensure the highest standards of performance and reliability.

We are committed to providing our customers with exceptional products and services. For more information or to discuss your specific hydraulic valve needs, please contact our sales team. We are dedicated to assisting you with your project and providing customized solutions to meet your requirements.

If you have any questions about DCV Series Multi-way Directional Valve, please feel free to leave a message through our backend system, and I will provide you with product information as soon as possible.

In addition to Hydraulic Multi-way Directional Valve, we also manufacture a range of other products including Hydraulic Lock, Overflow Valve, Manual Control Valve, Solenoid Valve,and more.
