Vision Guided Six Axis Robot Dispensing Machine

Intelligent Six-Axis Robot Dispensing Solution

The Vision Guided Six Axis Robot Dispensing Machine is designed for manufacturers that need accurate and flexible dispensing on complex products. With a six-axis robotic arm, the equipment can move freely in multiple directions and complete dispensing, coating, and filling processes in three-dimensional space. Compared with traditional fixed-axis machines, this system provides better flexibility for curved surfaces, irregular structures, and products with different shapes.

Parameter	Detail
Equipment Name	6-Axis Robot Dispensing Machine
Motion Performance	6 DOF robotic arm, adjustable posture in full 3D space; repeat positioning accuracy ±0.02mm for premium models
Working Radius	700mm–1800mm
Load Capacity	6kg–500kg optional
Compatible Adhesives	Hot melt glue, silicone, UV glue, epoxy resin, two-component AB glue
Glue Supply Precision	Single-component: 20–800KPa adjustable air pressure; two-component dispensing accuracy ≤±1%
Optional Vision Function	Automatic position compensation, online defect detection for overflow/broken glue
Control Mode	Touch HMI, offline programming + online teaching, MES system compatible, full data traceability
Production Capacity	Replace ≥3 manual workers; dual-station design boosts output by over 50%
Product Change Time	Only 15 mins for program switch, no fixture re-customization
Protection Grade	Industrial version IP67, stable under dust, oil and high humidity conditions
Expandable Functions	Dispensing + screw locking / workpiece handling composite processes

The machine integrates a high-precision servo control system, intelligent vision positioning, and customized glue supply modules to handle various industrial adhesives, including silicone, UV glue, epoxy resin, hot melt adhesive, and AB glue. As an advanced adhesive dispensing robot, it can automatically identify product positions, correct dispensing paths, and maintain stable glue output during continuous production.

Precision Dispensing for Complex Production Needs

The six-axis structure allows the dispensing head to adjust its angle during operation, keeping the glue nozzle at the correct position even on uneven or three-dimensional surfaces. This makes it suitable for 3D Complex Curve Dispensing Equipment applications where traditional dispensing methods cannot achieve accurate coverage.

The system supports different dispensing valves and material supply methods according to production requirements. With vision guidance, the machine can reduce positioning errors and improve product consistency. It also supports online teaching, offline programming, and factory data communication, making it easier to integrate into modern automated production lines. As a flexible robotic dispensing solution, it can be expanded with inspection systems, fixtures, and multi-station functions for different manufacturing processes.

Why Choose Mingzheng

Mingzheng focuses on developing customized automation solutions based on each customer's production process. From robot configuration and glue management to vision positioning and complete line integration, our engineering team provides professional support to help customers achieve stable and efficient production.

The MES Connected Automatic Dispensing Line option allows seamless connection with smart factory systems, while the stable structure and intelligent control technology help reduce manual operation, improve dispensing accuracy, and increase long-term production efficiency.
