Power D-Sub Connectors 13 pin:

13W3 Wire-Solder High-Current d Connector: The Golden Ratio of Signal & Power, The Ultimate in Wiring Flexibility

In the extensive D-sub family, the 13W3 Wire-Solder High-Current dsub connector stands out from numerous hybrid layouts. With its unique "10+3" configuration and wire-solder installation, it offers exceptional adaptability. It is precisely positioned for applications requiring a balance of moderate power, signal density, and customized cabling.

I. Core Differentiation from Competitors

The unique value of the 13W3 lies in the fact that it is not just about "conducting electricity." It is tailor-made for systems requiring 3 high-current power feeds + 10 control/feedback signals.

Compared to the 21W4, it offers a higher proportion of high-current contacts.

Compared to the 27W2, it delivers stronger power output capabilities.

Compared to the 5W5, it retains ample signal channels.

II. Unique Advantages of Wire-Solder Installation

Unlike the straight or right-angle PCB mount versions found in other series, the 13W3 wire-solder design brings three distinct advantages:

1. Flexible Cable Customization:

It allows direct soldering of cables with various gauges and materials, accommodating a wide range from AWG 30 to AWG 12 without being restricted by PCB trace limitations.

2. Convenient On-Site Maintenance:

In industrial field settings or outdoor base stations, technicians can simply cut and re-solder wires. This eliminates the need to replace the entire PCB or connector assembly, significantly reducing operation and maintenance costs.

3. Ideal for Prototypes & Low-Volume Production:

During the R&D phase, there is no need for custom tooling or specific PCB designs. Hand-soldering allows for rapid validation, effectively shortening the product time-to-market.

Technical Parameters：

Rated Current Male: 10AMP~40AMP

Rated Current Female: 10AMP~40AMP

Contact Resistance: 25mohms MAX

Insulation Resistance: 1000Mohms MIN

Withstanding Voltage: 1000VRMS

Operating Temperature: -55°~125°

Mechanical Life: 500 Cycles

Applicable Wire Gauge: AWG 8/10/12

Mounting Method: Cable Plug-In

Packaging Method: Blister/Outer Carton

Environmental Requirements: Meets EU Environmental Requirements

Brand: pandi

Application Scope: Mechanical Equipment, CNC Systems, Instruments & Meters, etc.
