This Anti-Vibration Pump Mounting Pad uses medical-grade silicone. The hardness is 70±5 Shore A. The size is 38.00 × 32.00 × 5.00 mm. The part is a flat rectangular silicone piece with a compact cuboid shape. The four corners use right angles. The edges have small chamfers. This removes sharp corners and makes installation safer for medical devices.The pad has two working surfaces. One side has a textured pattern. The pattern can be concentric or labyrinth style. The texture increases friction and helps reduce vibration and slipping. The other side is smooth and flat. This side stays in close contact with the pump housing or device base.Four through-holes sit at the corners. Screws pass through these holes to fix the pad in place. This makes installation accurate for miniature pumps used in medical equipment. The structure works well with Sealed Diaphragm Pump, Sealed Fluid Transfer Pump, and Micro Sealed Hydraulic Pump assemblies.Many fluid control systems use Mini Sealed Valve and Sealed Fluid Direction Control Valve technology. In these systems vibration control is important. Vibration isolation helps the system run in a stable way. It also protects sealing parts such as Pressure Seal Components, Fluid-Tight Diaphragms, and Diaphragms & Sealing Gaskets.
1.Functions
1)Micro Pump Vibration Isolation:The silicone pad sits between the pump body and the equipment base. The material absorbs high-frequency vibration during pump work. This keeps vibration from moving into the device housing. The system stays stable when it uses Sealed Diaphragm Pump, Sealed Fluid Transfer Pump, or Micro Sealed Hydraulic Pump modules.
Stable vibration control also protects precision sealing parts. These include Fluid-Tight Diaphragms, Pressure Seal Components, and Sealing Elements for Valves. These parts often appear in compact fluid control modules.
2)Noise Reduction:Micro pumps create structural noise during high-frequency operation. The silicone pad blocks vibration noise from spreading through the structure. The medical device runs more quietly. This helps create a calmer medical environment during diagnosis or treatment. Devices with Mini Sealed Valve or Sealed Fluid Direction Control Valve systems benefit from this isolation.
3)Pump Fixation and Anti-Slip Stability:Four mounting holes allow screw fixation. The pump stays firmly in position during operation or transport. The textured surface adds anti-slip friction. The pad helps stop movement or loosening of pumps that include Micro Sealed Hydraulic Pump, Sealed Fluid Transfer Pump, and nearby Pressure Seal Components.
4)Structural Isolation and Protection:The silicone pad separates the pump housing from the metal base. Direct contact does not occur. This reduces wear and mechanical damage on surfaces. The silicone layer also gives electrical insulation and mechanical buffering. Nearby Sealing Elements for Valves, Diaphragms & Sealing Gaskets, and Gasket & Membrane Assemblies receive extra protection.
2.Performance Characteristics
1)Medical-Grade Silicone Material:The pad uses high-purity medical silicone. The material has good biocompatibility. Harmful extractables are not present. The hardness of 70±5 Shore A provides vibration absorption and structural support at the same time.This balance supports stable pump operation in Sealed Diaphragm Pump, Sealed Fluid Transfer Pump, and Micro Sealed Hydraulic Pump systems. Sensitive sealing parts such as Fluid-Tight Diaphragms and Pressure Seal Components remain protected.
2)Dual-Surface Functional Design:The textured side increases friction and helps control vibration. The smooth side keeps even and tight contact with equipment structures. This design improves installation stability in devices that contain Mini Sealed Valve, Sealed Fluid Direction Control Valve, and Gasket & Membrane Assemblies.
3)Wide Temperature and Environmental Resistance:The silicone material keeps stable performance from –40°C to 120°C. The material also resists moisture and hydrolysis. The pad works well in hospital environments where cleaning and sterilization happen often.These conditions help protect nearby Sealing Elements for Valves, Diaphragms & Sealing Gaskets, and Pressure Seal Components from vibration stress.
4)Low Compression Set for Long-Term Stability:The silicone shows good elastic recovery. The material keeps vibration damping ability after long mechanical load. Pump systems with Sealed Fluid Transfer Pump, Sealed Diaphragm Pump, or Micro Sealed Hydraulic Pump modules remain stable during long use.
5)Medical Safety Compliance:The medical silicone has no odor. Harmful residues are not present. The material meets hygiene and safety rules for medical equipment. The pad works safely with devices that include Fluid-Tight Diaphragms, Sealing Elements for Valves, and Gasket & Membrane Assemblies.
3.Typical Applications
1)Infusion Pumps and Syringe Pumps:The pad isolates vibration for micro pumps inside infusion and syringe pump systems. Stable pump work supports accurate fluid delivery. These systems often use Sealed Diaphragm Pump, Mini Sealed Valve, and Fluid-Tight Diaphragms.
2)Laboratory Analytical Equipment:The pad suits biochemical analyzers, hematology analyzers, and laboratory automation systems. These systems use micro pumps for fluid transfer. The pad reduces vibration interference during measurement. Many of these systems include Sealed Fluid Direction Control Valve and sensitive Pressure Seal Components.
3)Medical Diagnostic Devices:The pad fits diagnostic equipment such as ultrasound systems and monitoring devices. Vibration isolation protects internal fluid control modules. These modules often contain Sealing Elements for Valves, Diaphragms & Sealing Gaskets, and Gasket & Membrane Assemblies.
4)Portable Medical Devices:The pad works well in portable ventilators, compact infusion pumps, and mobile medical equipment. The silicone absorbs shock and vibration during movement. Micro Sealed Hydraulic Pump and Sealed Fluid Transfer Pump assemblies receive protection.
4.Problems Solved
1)Prevents Vibration-Induced Accuracy Loss:Micro pump vibration can cause fluid delivery error or measurement deviation. The mounting pad absorbs vibration. Systems that use Sealed Diaphragm Pump, Mini Sealed Valve, and Fluid-Tight Diaphragms keep stable performance.
2)Reduces Noise in Clinical Environments:High-frequency pump operation may create noise in medical devices. The silicone pad blocks vibration noise inside the structure. Equipment with Sealed Fluid Direction Control Valve systems runs more quietly.
3)Eliminates Pump Displacement Risks:Micro pumps may move during operation if fixation is weak. The screw-mount structure and textured surface keep the pump stable. Nearby Pressure Seal Components and Sealing Elements for Valves stay protected.
4)Ensures Material Safety in Medical Applications:Poor damping materials may release harmful substances. This pad uses medical-grade silicone that meets strict safety requirements. The material works safely with Diaphragms & Sealing Gaskets and other precision sealing parts.
5)Reduces Maintenance Costs:The silicone structure is durable and stable. Replacement frequency becomes lower. The pad protects Micro Sealed Hydraulic Pump, Sealed Fluid Transfer Pump, and Sealed Diaphragm Pump systems during long service.
