2.54mm Machined Straight Socket Connector

4 week ago

7 0

HuiZhou Antenk Electronics Co., LTD

 5 year year

Product details

Manufactured by Huizhou Antenk Electronics Co., Ltd, the MFHES series 2.54mm machined straight socket connector delivers stable signal transmission for various PCB electronic devices, offered in four structural variants Type1, Type2, Type3 and Type4 with single or double row layouts. Per drawing specifications, the insulator is high-performance PPS material meeting UL94V-0 flame retardant standard, paired with six-finger beryllium copper contact clips and brass sleeves. It fits mating pins from 0.7mm to 0.9mm diameter, rated at 3A current with maximum 10 milliohms contact resistance, sustaining 1000V RMS dielectric strength and providing stable insertion and withdrawal force for consistent mating. Single row versions cover 1 to 40 contacts while dual row models support 2 to 80 contacts to meet multi-channel connection demands. Our full production workflow includes independent precision mold development, high-precision beryllium copper machining, high-temperature PPS injection molding, multi-thickness gold or tin electroplating, automatic assembly and full mechanical cycle testing. Taiwan precision punchers and Japanese injection machines keep all PCB layout dimensions under tight unified tolerances for standard through-hole wave soldering.

This straight machined socket connector supports tray, bag, tube and tape reel multiple packaging modes to satisfy manual and automated production lines. Operators solder the straight tail pins onto printed circuit boards following the official PCB layout diagram, then match with corresponding male pin headers to build complete signal circuits. It is widely applied in industrial control modules, communication equipment, digital cameras, household intelligent appliances, automotive auxiliary electronics, memory storage devices and precision measuring instruments. During application, users must select matched pin diameter to avoid poor contact, control soldering temperature properly to prevent PPS insulator deformation, and store unused connectors in dry sealed bags to protect beryllium copper clips from oxidation. All products comply with EU RoHS and REACH environmental standards, most specifications obtain UL certification numbered E472792, and our factory has passed ISO9001, ISO14001 and IATF16949 automotive quality management certifications.

Compared with other connector manufacturers, Antenk owns more than 250 sets of self-developed plastic molds and 180 sets of precision metal machining molds, supporting flexible customization of row type, contact quantity and surface plating thickness for this machined socket series. Our 10000-square-meter production plant with 250 professional staff is equipped with over 180 automatic assembly machines and 20 professional testing instruments, guaranteeing uniform batch quality and rapid large-volume delivery. As a holder of Guangdong Famous Trademark qualification, more than 70 percent of our precision signal connectors are exported to global markets. Our multi-stage incoming, in-process and finished product inspection system brings excellent mechanical durability with minimum 500 mating cycles, effectively reducing signal interruption caused by worn contact clips and establishing long-term reliable cooperative partnerships with clients across Europe, America, Southeast Asia and other international regions.
