BMS Equalization Control Board 485 Parallel Cable XH2.54 4Pin Twisted Pair Harness Length 330mm

2 week ago

0 0

Shenzhen Fubang Wire harness Co.,Ltd

 2 year year

Product details

This XH2.54 4Pin 485 parallel communication harness is specially designed for BMS equalization control board data transmission inside lithium battery packs. Adopting twisted wire layout with fixed twist pitch, the cable effectively restrains electromagnetic interference, ensuring stable signal transmission during battery balancing operation. As an essential internal connection component, it belongs to professional vehicle battery pack wiring harness, widely matched with energy storage battery management modules and onboard battery equalization systems.

BMS Equalization Control Board 485 Parallel Cable XH2.54 4Pin Twisted Pair Harness Length 330mm

The harness is constructed with UL1007 22AWG tinned copper wires, equipped with dual-end XH2.54 4Pin female lock connectors. Color-coded internal conductors simplify wiring identification during assembly. Multiple layers of heat shrink tubing are applied for wire protection, and customized printed marking sleeves are reserved for product traceability. Our engineering team supports flexible dimension adjustment, which enables us to provide tailored automotive wiring assembly according to different battery cabinet installation layouts.

Every harness undergoes comprehensive quality verification. We implement 100% continuity testing, withstand voltage inspection and resistance detection to eliminate hidden risks such as poor contact and signal interruption. Beyond standard specifications, we can adjust wire length, connector types and shielding structures. Whether prototype sampling or mass production, we can optimize the design of automotive cable assembly to adapt to complex working environments of battery systems.

Item	Description
Product Name	BMS Equalization Control Board 485 Parallel Cable XH2.54 4Pin Twisted Pair Harness Length 330mm
Type	Signal Communication Wiring Harness / Custom 485 Twisted Pair Data Cable
Voltage	DC 500V Test Voltage, Signal Level Low Voltage Application, Custom Voltage Available
Pins Material	Tin-Plated Copper XH2.54 Crimp Terminals
Plug Material	White PA66 XH2.54 4Pin Connector Housings with Lock Buckle, Black Full-Length Heat-Shrink Tubing Protection, UL1007 PVC Insulated Wires, White Printed Heat-Shrink Label
Working Temperature	-40℃ ~ +105℃, Industrial & Energy Storage Grade
Length	330±5mm Total Length, Custom Length Fully Supported
Minimum Insulation Resistance	≥10MΩ
Maximum Conduction Resistance	≤3Ω
Compliance Standard	RoHS Environmental Compliance
Application Fields	BMS battery equalization control board 485 communication wiring, energy storage system internal signal connection, battery pack balancing module data transmission, lithium battery management system internal harness, customized energy storage equipment communication cable
Specific Shipping Cost	Please Contact Us

This communication wiring harness is mainly used for signal interconnection between battery equalization boards, energy storage BMS internal communication, lithium battery pack monitoring modules and other scenarios. The anti-interference twisted structure makes it suitable for compact battery cabin installation. If you need matching internal connection accessories for battery equipment, our customized service can develop exclusive vehicle battery pack wiring harness to fit your equipment structure.
