Blocking
|
Parameter |
Symbol |
Min |
Max |
Typ |
Unit |
Conditions |
|
|
Repetitive peak reverse voltage |
VRRM |
|
600 |
|
V |
Tj = -40 °C to 190 °C |
|
|
Non repetitive peak reverse voltage |
VRSM |
|
650 |
|
V |
Tj = -40 °C to 190 °C |
|
|
Repetitive peak reverse current |
IRRM |
|
75 |
|
mA |
Tj = Tjmax , V = VRRM |
|
Conducting
|
Parameter |
Symbol |
Min |
Max |
Typ |
Unit |
Conditions |
|
|
Average value of forward current |
IF(AV) |
|
7100 |
|
A |
50 Hz sinewave,180o conduction, Tc = 85 °C |
|
|
RMS value of forward current |
IF(RMS) |
|
11200 |
|
A |
50 Hz sinewave,180o conduction, Tc = 85 °C |
|
|
Peak one cycle surge (non repetitive) current |
IFSM |
|
55 |
|
kA |
50 Hz sinewave,180o conduction, Tj = Tjmax, VR = 0 |
|
|
I square t |
I2 t |
|
15125 |
|
kA2s |
Tj = Tjmax |
|
|
Peak forward voltage |
VFM |
|
0.85 |
|
V |
Forward current 4500 A, Tj = Tjmax |
|
|
Threshold voltage |
VF(TO) |
|
0.7 |
|
V |
Tj = Tjmax |
|
|
Forward slope resistance |
rF |
|
0.033 |
|
mΩ |
Tj = Tjmax |
|
