With the rapid development of domestic economy, consumers pay more and more attention to the freshness, safety and convenience of food. The food preserved by modified atmosphere with pallet packaging will be more and more popular.
JNSW3 Automatic map tray sealer machine
Key elements of modified atmosphere (MA) packaging for freshness preservation
①Maximum gas displacement rate:
Gas displacement refers to the process of using a vacuum pump to expel air from packaging containers or employing a gas displacement method to replace air within the container. This process removes the original air and fills the container with a carefully proportioned mixture of preservation gases (such as oxygen, carbon dioxide, or nitrogen). The higher the gas displacement rate, the more precisely the mixed gases can be controlled, thereby making it easier to manage both the shelf life and storage duration of food products. Different packaging types require tailored displacement solutions, with the final gas mixture ratio remaining the sole criterion for quality assessment.
② Precise gas mixture ratio:
Taking carbon dioxide (CO2) as an example, it is the most critical gas in modified atmosphere packaging. It inhibits the growth of bacteria and fungi. The accuracy of CO2 concentration directly affects the shelf life of food. Currently, the most precise equipment for mixing different gases in specific ratios achieves a self-made gas mixture accuracy better than ±2%.
③High-barrier packaging materials:
High barrier material is an important part of modified atmosphere packaging, which can ensure the mixed preservation gas inside the package does not leak out and the outside gas does not penetrate.
④ Suitable storage temperature:
The benefits of modified atmosphere (MA) packaging for food preservation are based on maintaining consistent environmental conditions. At low temperatures, carbon dioxide's antibacterial effect is significantly enhanced, while microbial growth slows down and food respiration decreases. The recommended cold storage temperature range is 0-4°C.
⑤ Excellent sealing performance:
A clear and intact sealing pattern is the primary requirement for packaging. Poor sealing (e.g., narrow creases, wrinkles, or bubbles) can cause the preservative gas to escape, significantly reducing the shelf life of food and potentially damaging the product's brand image.
⑥ Consistent gas mixture ratio:
However, when stored at the same temperature but in different gas environments, food quality and shelf life can vary significantly. In the modified atmosphere (MA) preservation packaging process, we require that the proportion of preservation gases in all packaging batches be consistent, with an error margin of ≤1% per batch. This ensures that under identical conditions of time and temperature, the food maintains consistent quality, thereby preventing subtle yet long-term economic losses.
Main Configuration Functions of the Equipment
1 Configuration Details
1.1. 304 stainless steel body and shell.
1.2. High-quality aluminum 6061 anodized.
1.3. Omron sensor.
1.4. PLC control system developed independently.
1.5. Taiwan Velon touch screen.
1.6 Panasonic sensors.
1.7. Yadeke Cylinder
1.8. The sealing mold shall be customized according to the sample box provided by the customer, with the actual sample box as the standard.
2 Technical Features:
2.1. Real-time fault prompt function.
2.2. Air pump water release reminder.
2.3. Packaging counting function.
2.4. High efficiency and fast processing (one process in 7 seconds)
2.5. Precision film walking system.
2.6. Gas pressure detection and alarm.
2.7 Tool-free mold replacement.
Equipment Features:
①Patent air flow replacement:
The gas replacement rate is 99% by means of gas displacement.
②Self-developed gas mixer:
The gas mixer maintains stable gas ratios and precision regardless of pressure fluctuations in the gas source. The packaging machine, with its high displacement rate, ensures more accurate gas ratios and achieves a mixing precision of ±1%.
③ International brand Yadea's moving components:
The product features stable and reliable quality with a long service life, ensuring uninterrupted and continuous operation of equipment without failures, thus guaranteeing uninterrupted packaging production for users.
④ International brand CNC operating system:
Taiwan Weilun Programmable Controller ensures long-term operation and safety, guaranteeing safe production for both machinery and personnel.
⑤ Automatic mode:
Easy to operate, high packaging efficiency, labor-saving and high economic benefits
Technical parameter
| Model |
JNSW3-E |
Packaging speed (times/min) |
8-9 |
Working pressure (MPa) |
0.6-0.8 |
| Maximum tray size (mm) |
260x180x80(x3) |
Rough weight （Kg） |
480 |
Machine weight （Kg） |
380 |
| Maximum width of the roll film (mm) |
630 |
Maximum diameter of the roll membrane (mm) |
300 |
Electrical Requirement（V/Hz） |
380/50 |
| Machine size (mm) |
1633*943*1442 |
Packing measurement （mm） |
1780*1180*1750 |
Consume power（kw） |
2.8kW |
