Four Column SBR Material Embossing Machine

Large-Format Embossing for SBR, CR and EVA Materials

The Four Column SBR Material Embossing Machine is designed for factories that need to press patterns onto SBR, CR, EVA and leather materials. The GC series uses a multi-cylinder four-column structure to keep the working pressure more evenly distributed across the table. It fits production work for shoe materials, car mats and sports goods, especially when the mold covers a large area.

Model	Travel	Working pressure	Working surface	Motor Power	Remarks
GC‑80	300mm	80T	3650*1600mm	5.5KW	Four‑column three‑cylinder
GC‑100	300mm	100T	3650*1800mm	5.5KW	Four‑column four‑cylinder
GC‑120	300mm	120T	3650*2000mm	7.5KW	Four‑column four‑cylinder
GC‑140	300mm	140T	3650*2200mm	7.5KW	Four‑column four‑cylinder
GC‑180	300mm	180T	4500*1800mm	11KW	Four‑column six‑cylinder

Compared with a small SBR embossing machine, this series gives manufacturers much more working space. The available models range from 3650 × 1600 mm to 4500 × 1800 mm, so the machine can be matched with different mold sizes and product dimensions.

Four‑Column SBR Material Embossing Machine

Three Points That Matter in Production

Multi-cylinder structure for more even pressing

When a large mold is used, pressure balance becomes important. The GC series uses three, four or six cylinders depending on the model, working together with the four-column guide structure. This helps keep pressure more evenly distributed across the working table and is particularly useful for large SBR and CR sheets. For manufacturers comparing a hydraulic embossing press machine, this setup is worth paying attention to when the mold size is large.

Hydraulic hot embossing machine for fabric

One machine for different material jobs

SBR, CR, EVA and leather do not always have the same forming requirements. This machine can be used for different pattern pressing jobs by changing the tooling according to the material and product. It can work as an EVA shoe material embossing machine for footwear production, while also handling rubber and leather products used in other industries.

Speed and heating can be adjusted to the job

The GC series supports single-speed or two-speed operation, giving operators more control during pressing. The electrical system also supports manual and semi-automatic cycles, while a heating function is available for processes that need heat during embossing. For applications involving rubber patterns, shoe materials or fabric surfaces, this gives the machine more room to adapt than a basic cold pressing setup.

Hydraulic Embossing Press for Car Mat Leather

Why Choose Guocheng?

Guocheng offers several GC models instead of using one fixed machine size for every project. GC-80 starts with an 80T working pressure and a 3650 × 1600 mm table, while GC-180 reaches 180T with a 4500 × 1800 mm working surface. The cylinder arrangement also changes with the model, from three cylinders to six cylinders.

That range makes it easier to choose according to the actual product and mold. If you are looking for an SBR CR embossing machine for car mats, footwear materials or sports products, the right model can be selected based on working area and required pressing force rather than simply choosing the largest machine.

Applications

The GC series is suitable for pattern pressing and forming of:

SBR car mats

CR rubber products

EVA shoe materials

Leather products

Footwear materials

Sports goods

Patterned rubber sheets

Other large-area material embossing applications

For car mat production, the large working table makes the machine suitable for molds covering a wide area. Depending on the material and process, it can also be considered alongside an embossing machine for car mat production or an embossing heat press machine where heated forming is required.
