DH‑7 Series Joystick

Product Overview

DH‑7 Series Joystick is a hydraulic pilot control joystick assembly specially designed for Doosan excavators. As the core operating component inside the cab, it transmits operator manipulation signals to the hydraulic system of the engineering Machine. This pilot joystick adopts integrated hydraulic valve‑body structure, achieving proportional control of flow and pressure. It accurately governs the direction and running speed of boom, arm, bucket and swing movements. Stable pilot output guarantees smooth, responsive operation of the whole Machine. Widely used for original equipment matching and aftermarket spare‑part replacement for Doosan DH‑7 series excavators.

Technical Specifications

- Model Series: DH‑7 Pilot Joystick Assembly

- Applicable Equipment: Doosan DH55‑7, DH135‑7, DH215‑7, DH225‑7, DH300‑7 excavators

- Operation Axis: Dual‑axis pilot control

- Control Type: Hydraulic pilot proportional valve

- Reset Mode: Spring automatic centering‑return

- Grip Option: With or without auxiliary thumb buttons

- Working Pilot Pressure: 3‑5 MPa

- Valve‑body Material: High‑strength cast alloy

- Protection: Dust‑proof rubber bellows against construction‑site dirt

- Installation: Standard cabin mounting flange

- Main Function: Send pilot control signals to the hydraulic system of target Machine

Working Principle

When the operator tilts DH‑7 Series Joystick, internal spool inside the pilot valve shifts accordingly. Low‑pressure pilot hydraulic oil flows out in proportion to handle deflection angle. These hydraulic control signals are delivered to the main multi‑way valve within the hydraulic system. The main valve then changes oil‑flow direction and volume, driving hydraulic cylinders and swing motor of the Machine. Upon releasing the handle, built‑in return springs push the joystick back to neutral position, cutting pilot oil output and stopping all machine movements. Well‑matched spool‑sleeve fit ensures sensitive, lag‑free command transmission for the hydraulic system.

Core Advantages

1. Ergonomic handle‑grip design, smooth operating feel, reduces operator fatigue during long‑shift work of the Machine.

2. Precision‑machined pilot valve spool‑sleeve pair, stable proportional pilot‑oil output for accurate action control of the hydraulic system.

3. Reliable spring‑centering mechanism; clear neutral positioning, effectively preventing mis‑operation of the Machine.

4. Heavy‑duty dust‑proof rubber bellows, resisting dust, mud and splash water, adapting to harsh construction‑site conditions.

5. Complete assembly unit, direct bolt‑on replacement; no complicated modification required for existing Machine.

6. Strict casting and assembly standards, low internal leakage, long service‑life and lower overall maintenance cost for the hydraulic system.

Application Scope

DH‑7 Series Joystick serves as factory‑standard operating controller for Doosan DH‑7 series excavator Machine. It provides pilot‑command input for the complete hydraulic system. Mainly deployed in construction sites, earth‑moving projects, mine‑site excavation and machinery repair workshops for overhaul and component renewal.
