Spacer Frame Bending Machine
Description of Spacer Frame Bending Machine
1.Aluminum bar bending machine, color can be customized according to customers, bending Angle accurate, used for insulatin
Corner folding method can greatly improve the service life of middle glass, three less empty corner division accounts for % of the system, corner bending can be a good long system of airtight, lift the service life with the maturity of domestic rich frequency welding can bend aluminum bar, glass life
We for its aluminum bar shape ruler control in the man mm so for the glass beautiful and equipment is made than the station, glass ruler meter =2m, +3m aluminum bar should be made in the main 15m such folded aluminum shape inch to strictly hand the national standard requirements this is suitable for hollow home or equipment manufacturers. 2. Angle error control. During the bending process of aluminum strip, the Angle ruler will change due to the extrusion deformation of the tool head. If the adjustment of the nozzle clearance will cause the thickness of butyl glue coating changes, on the hollow quality. Therefore, the Angle error control after aluminum bar bending is also very important. This point is not reflected in the national standard. According to the practice experience and domestic and foreign application, we believe that the Angle error at least should be ≤0.2mm on the basis of the body error covering the aluminum bar. All glass factories should pay close attention to this Angle when selecting equipment
Equipment details
| NAME | BRAND | NAME | BRAND |
| PLC | GERMAN SIEMENS | Triplet | Taiwan AIRTAC |
| Low voltage electrical apparatus | GERMAN SIEMENS | Cylinder | Taiwan AIRTAC |
| Servo motor | GERMAN SIEMENS | Solenoid valve | Taiwan AIRTAC |
| Servo driver | GERMAN SIEMENS | Switch power | Taiwan TEND |
| Relay | JAPAN OMRON | TOUCH SCREEN | Taiwan WEINVIEW |
| Sensor | KOREA AUTONICS | GUIDE | Taiwan TBI |
| Max.bending size | 2000mm*2000mm (2500mm*2500mm) |
| Min.bending size | 250mm*200mm |
| Aluminum spacer width | 5.5-27mm |
| Dimensional error | ±0.5mm |
| Angle error | ±1º |
| Processing speed | ≤26s |
| Air supply | ≥0.65MPa |
| Total power | AC220/380V 50Hz 2.5KW |
| Dimension |
10500mm*2200mm*2600mm |
