LJTB01 Butyl Extruder Machine
The LJTB01 butyl extruder machine is used for spreading aluminum spacer
frames evenly with hot melt butyl. LJTB01 butyl extruder machine use large
electrical control panel which makes the operation more easier. The conveyor
of aluminum is controlled by frequency converter, and the speed can be adjusted
from 0m/min to 47m/min, which has the fastest speed in China
Germany Siemens spares
Adopt Siemens brand, extending working life, stable performance.
Upright Glue Cylinder
Adopt the special structure, easy to change butyl.
² Technical Data
Squeeze pressure |
10-18MPa |
Temperature |
110~140℃ |
Aluminum spacer width |
4-30mm |
Speed |
0-47m/min |
Diameter of butyl cylinder |
200mm |
Air supply |
0.4m³/min |
Air pressure |
≥0.6MPa |
Total power |
380V, 5KW, 50HZ |
Dimension |
2600×680×1100mm(L×W×H) |
Weight |
650kg |
1. Filter out debris automatically through auto exhaust, keep spreading quickly and evenly.
2. Quickly speed of warming, improve work effect.
3. Adjustable coating speed, can up to 0-47m/min.
4. Can save about 40% materials, only 5g/m.
Other Insulating Glass Equipment of our company:
1.Insulating Glass Production Line
2.Spacer Bending Machine
3.Desiccant Filling Machine
4.Butyl Extruder Machine
5.Insulating Glass Sealing Robot
6.Glass Washing Machine
