GHZ4228 GHZ4230 Automatic Band Sawing Machine For Metal
Product Description
The main performance characteristics:
1. extremely rigid dual-column cast -iron construction
2. with heavy swivel console
3. Three cutting speeds -directly shifted via main drive
4. motor
5. infinitely variable saw frame feed
6. Horizontal saw frame swivels up to 45 °
7. Saw frame automatically returns to home position at
8. the end of each cut
9. extra rigid ,adjustable saw blade guide
10. including hydraulic workpiece clamping with clamping pressure control
11. Standard equipment :hydraulic workpiece clamping ,1 saw blade belt ,material support stand ,coolant system ,work lamp
operation manual
12. Optional equipment :automatic blade breakage control ,fast drop protection devise ,hydraulic blade tension ,automatic chip
removal device ,various blade linear
13. speed ,blade protection covers ,wheel cover opening protection ,Ce standard electrical equipment
Product main technical parameters:
Specifications
GHZ4228
GHZ4230
GHZ-350
Cutting capacity 90°
Rectangular
300*200mm
320*280mm
320*300mm
Circular
-
330mm
280mm
Cutting capacity 45°
Rectangular
210mm
220x200mm
280x240mm
Circular
-
200mm
200mm
Saw blade speed
27\45\69m/min
27\45\69m/min
27\45\69m/min
Belt saw blade size
3505x27x0.9mm
3850*27*0.9
4115x34x1.1mm
Motor power
Main motor
2.2kw
2.2kw
3kw
Oil pump motor
0.55kw
0.55kw
0.55kw
Cooling pump motor
0.04kw
0.04kw
0.04kw
Overall dimension
1900x1400x1500
2000x1450x1550mm
2100x1500x1600mm
Weight
700kg
750kg
850kg
Details Display
