Transon TSD1390 Laser Engraving Machine
This 1390 CO2 laser engraving cutting machine is Transon 2021 new designed high safety laser machine. It can engrave and cut almost all nonmetal material include acrylic, wood, MDF, plywood, fabric, paper board, etc. All buttons operator can touch are safety 24V voltage, include the key switch,emergency stop button, LED light and led light on/off button. Machine up cover with mechanical lock, only when cover closed can machine start work, cover open machine stop work. Machine hybrid Servo motor with damage protection function, whenever they detect damage from motor, machine will stop work, and no laser come out from laser tube, this can greatly improve security when machine work.
Key words: small laser engraving machine, desktop laser engraving machine, CO2 laser engraver cutter, nonmetal laser engraver cutter, CNC Laser Cutter,Small Laser Cutter, multi heads laser cutting machine.
Model
TSD1390
Working area
1300mm*900mm
Laser power
40W/ 60W/80W/90W
Laser type
CO2 sealed laser tube, water-cooled
Worktable
Standard with Blade worktble
Engraving speed
0-50000mm/min
Cutting speed
0-30000mm/min
Highest scanning precision
2500DPI
Power supply
220v/50Hz , 110v/60Hz
Min. shaping character
English 1.0 x 1.0mm, Chinese 1.5 x 1.5mm
Graphic.format.supported
BMP, PLT, DST, DXF, AI
Software supported
CorelDraw, PhotoShop, AutoCAD,TAJIMA
Control system
High speed DSP control system brand Ruida or Leetro
Machine work software
RDWorks V8 (Ruida)
Laser output control
1-100% by setting in the software
Interface
USB 2.0
Driving system
Easy servo motors
Color separation
Yes
Optional part
Red dot pointer
Spare parts
Extra laser tube/Extra 1 lens and 3 mirrors
Machine size/ Plywood box size
1800mm*1360mm*1030mm/1900mm*1460mm*1200mm
Plywood gross weight
460kgs
Applicable Industries:
Suitable for industries such as billboards, artistic gifts, crystal ornaments, paper-cut engraving, bamboo embossment, printing, garments and leather industries, embroidery, interior decoration and frame fabrication, etc..
Applicable Materials:
Non-metal materials such as double-color sheets, acryl, glass, wood planks, paper, leather, rubber, marble, granite and tiles, etc..
Samples:
If you are interested in the product, contact 2bvideo.com for more information for more information
