Glass Loading Machine With Cantilever And Suckers
1. Jib crane is common light lifting equipment in modern production. It is fit for frequent lifting work of short distance between fixed positions. It has advantages of high efficiency, energy saving, convenience, occupying a small area and easy operation and maintenance. Jib crane has two structures of pillar stationary type and binding type. You can choose either.
2. It is operated by using compressed air instead of using electricity. All pneumatic components, we use Japanese SMC brand, while we use German SCHMALZ products for vacuum parts which is the most advanced technology of pneumatic and vacuum control in the world.
3. This machine is reliable and safe, easy to operate. The device is commonly used for glass loading and unloading work in glass deep processing process, such as cutting, grinding, cleaning, tempered, laminated and insulated. This device is usually used together with jib crane beam or gantry crane frame, depending on the client's requirements.
Technical data
Max. load |
300kg (500kg is optional) |
Rotated angle |
90° |
Upright height |
3400mm or 3900mm |
Rail length |
1000mm |
Quantity of sucker |
2 or 4 |
Air pressure |
0.5MPa-0.8MPa |
Other Insulating Glass Equipment of our company:
1.Insulating Glass Production Line
2.Spacer Bending Machine
3.Desiccant Filling Machine
4.Butyl Extruder Machine
5.Insulating Glass Sealing Robot
6.Glass Washing Machine
