0.1mΩ HYCS5216L100J00 Ribbon Bonded Flat Strip Shunt

0.1mΩ HYCS5216L100J00 Ribbon Bonded Flat Strip Shunt

5 day ago

2 0

Guangdong Kinwill Electronic Co., Ltd

 4 month year

Product details

Ribbon Bonded Flat Strip Shunt

Wire Bonded Flat Plate Shunt for high-current signal sampling applications, featuring tolerance down to ±0.5%. The shunt device has passed the AEC-Q200 automotive-grade reliability test, featuring high stability, extremely low thermoelectric potential and temperature coefficient.

Product Features:

Grooved Flat Plate Shunt for PCB Surface-Mount Current Sampling
Electron Beam Welded Structure for Robust Reliability
Superior Consistency, Reliability, Stability and Pulse Withstand Capability
Surface nickel plating and tin plating help with SMT (Surface Mount Technology) and oxidation protection
Maximum Tightening Torque: 10 N
Complies with RoHS & Environmental Regulations
Complies with RoHS & Environmental Regulations

*As a high-tech enterprise in a specialized field, our company is dedicated to providing high-strength, high-power, high-precision, high-reliability, ultra-low resistance, ultra-low temperature coefficient, ultra-low inductance value current sensing alloy resistors and shunt resistors. The product categories include Combined Shunts, Ribbon Bonded Flat Strip Shunts, U-Type Plug-In Shunts, High-Current Power Shunts, Pin-Type Shunt and more. We deliver related solutions for R&D, design, and production in sectors including automotive electronics, medical devices, smart home, measurement instruments, and energy storage BMS.
