CNC automatic 2-3-4 colors screen printing machine

12 month ago
24 0
Product details

Turntable Full Automatic screen printing machine for bottle caps

           Wine bottle caps play a vital role in wine packaging. They not only provide essential functions such as sealing, protection, and anti-counterfeiting but also serve as an important medium for showcasing brand image and enhancing product value. With increasingly fierce competition in the wine industry, consumers’ expectations for packaging quality and visual appeal continue to rise. Many premium wine brands are adopting advanced printing technologies on both bottles and caps to create unique and sophisticated decorative effects, strengthening brand recognition and market competitiveness.  Depending on the material, wine bottle caps can be classified into plastic caps, glass caps, metal caps, and other types. To meet the diverse requirements of different cap materials and decorative designs, modern bottle cap printing production lines widely utilize automatic bottle cap screen printing machines to achieve automated, precise, and efficient printing processes. Compared with traditional printing methods, intelligent automatic bottle cap screen printing machines integrate smart control systems, high-precision positioning technology, and automatic feeding functions, significantly improving printing stability while ensuring accurate color registration, strong ink adhesion, and the ability to handle complex patterns and customized designs.  For high-volume production environments, high-speed bottle cap screen printing machines offer outstanding advantages, including fast operation, continuous printing capability, and high production efficiency. These advanced printing systems can meet the demanding requirements of beverage packaging manufacturers for both production capacity and product quality. With excellent ink brightness, fine printing performance, and precise registration, modern bottle cap screen printing equipment enables the production of detailed text, brand logos, anti-counterfeiting marks, and other high-quality decorative elements, providing reliable automated printing solutions for wine, spirits, and premium beverage packaging.  By adopting automated and intelligent bottle cap screen printing technology, manufacturers can further improve production efficiency, reduce labor costs, and enhance the visual appeal and brand value of their products. Advanced automatic bottle cap screen printing machines, intelligent bottle cap automatic screen printing machines, and high-speed bottle cap screen printing machines provide powerful solutions for companies seeking higher-quality packaging and stronger competitiveness in the global market.

Structure

  • Feeding mechanism: Usually a vibration plate is used for automatic material distribution or a crawler feeding structure, which can automatically feed the wine bottle caps into the printing position in turn. Some are also equipped with optical fiber detection devices to realize the function of no material prompt and no printing.
  • Transmission mechanism: Usually a flat turntable is used, and the turntable is controlled by a high-precision divider, which can accurately transmit the bottle caps to each station.
  • Printing system: Generally, the printing heads are arranged in sequence in the circumferential direction of the turntable. The printing and rotation movements of the printing heads are controlled by servo motors. The turntable drives the wine bottle caps to pass through the screens of different colors for printing in sequence to realize the three-color printing function.
  • Positioning system: Mostly adopt pneumatic latch type or visual positioning system, such as dual camera visual positioning, to ensure the accurate position of the wine bottle caps during the printing process, and the positioning accuracy can reach 0.01mm or even higher, to ensure the registration accuracy of the printed pattern.
  • UV Drying unit: Generally, a UV/LED drying system is equipped at the station behind each printing head. After printing, the ink is quickly dried and cured, so that the ink is firmly attached to the surface of the wine bottle cap to prevent the pattern from blurring or falling off.
  • Control system: It consists of a PLC programmable controller and a touch screen, which can realize the functions of parameter setting, operation control and fault diagnosis of the equipment. It is easy to operate and maintain.

Features

  • High efficiency: The turntable design can realize continuous cycle printing, fast printing speed, and can print thousands of wine bottle caps per hour, greatly improving production efficiency.
  • High precision: The positioning system is accurate, which can ensure the color registration accuracy of three-color printing, and the printed pattern is clear and accurate, meeting the high quality requirements of the surface decoration of wine bottle caps.
  • Strong adaptability: It can be applied to wine bottle caps of various materials and shapes, such as plastic, glass, metal and other materials, as well as wine bottle caps of different shapes such as round and square.
  • Easy operation: It is operated through the touch screen, and the parameter setting is intuitive and simple. The operator can master the operation method of the equipment after simple training.
Samples of bottle caps automatic screen printing machine



Fully automatic 3 colors screen printing machine for lids//Technical Parameters

  • Round-object Max printing stroke: 100 mm;
  • Oval-object Max Printing stroke: 80 mm;
  • Round-object Max Printing speed: 4000 pc/h;
  • Oval-object Max Printing speed: 4500 pc/h;
  • Work piece size(Round): Diameter:25-100 mm;Length:60-300 mm;
  • Work piece size( Oval): Width:25-260 mm, Length:60-300 mm;
  • Power supply: AC380V,3Phase ,45A/(1-3Colour),100A/(4-5Colour);
  • UVLED  Lamp wattage: 1KW/pc;
  • UV Exhaust fan wattage: 0.2KW;
  • Exhaust rate: 11.6 m3/min;
  • Motor Wattage: 0.75KW;
  • Reduction gearbox : 1:7.5;
  • Feeding motor wattage : 0.75KW;
  • Fixture motor wattage : 0.5KW;
  • Vacuum Pressure : 500 mm/Ag;
  • Flame gas: Liquefied Petroleum gas( LPG);
  • Air : 6 Bar;
  • Outer size: 3820mm * 2640mm * 1980mm

Fully auto multi-color glass bottle UV screen printing equipment //Main configuration

  • Mainly Motor:SITI (Italy)
  • Feeding Motor :Panasonic(Japan)
  • PLC: Omron(Japan)
  • Rotary Encoder: Omron(Japan)
  • Sensor: Optec(Japan)
  • Touch Screen: Proface( Japan)
  • Switch: Schneider( France)
  • Contactor: Schneider (France)
  • Relay: Idec (Japan)
  • Inverter: Omron(Japan)
  • UV Curing System: Primarc ( England)
  • Pneumatic part: Festo (Germany
Machine install size
Drawing of automatic screen printing machine for bottle caps
