A Hassle Free Solution for Medium and Fine Crushing in Mining and Aggregate Operations
Cone Crusher Equipment Overview
The DLD Series Single-Cylinder Hydraulic Cone Crusher is a medium- and fine-crushing solution specifically designed for ore processing. It plays a pivotal role in aggregate production lines and mineral processing plants—receiving material from the primary jaw crusher and performing medium and fine crushing operations to meet requirements for product particle shape, gradation, and production capacity. The equipment comprises two sub-series: the DLDS medium-crushing type and the DLDH fine-crushing type, covering a wide capacity range of 25–2,181 tons per hour, with a precisely controllable discharge opening between 4 and 41 millimeters. Suitable for the medium and fine crushing of medium-to-high-hardness ores with a Mohs hardness of 16 or below, the series covers materials such as iron ore, basalt, limestone, granite, and river pebbles, and is widely used in cement plants, building materials production lines, and metal and non-metal mineral processing.
We specialize in the R&D, production, and sales of core equipment for mining and mineral processing, construction aggregate processing, and infrastructure engineering, covering a full range of products, including the DLKPC double-chamber hard rock crusher, DLHGC horizontal gyratory crusher, DLHPT multi-cylinder cone crusher, and jaw crushers.
Cone Crusher Equipment Highlights
Laminated crushing increases production capacity by 35%–60%. The crushing chamber is filled with material; as the moving cone swings, large quantities of rock are compressed, ground, and bent against one another, achieving “rock-on-rock” crushing rather than single-particle compression. This results in high-quality cubic-shaped final products with low flake and needle content, while ensuring more uniform liner wear and extending service life by 20%.
Helical bevel gear drive, low noise and high load capacity. The meshing is smoother than traditional straight-tooth bevel gears, offering higher load capacity and lower operating noise, thereby resolving the issues of gear tooth breakage and excessive vibration in older cone crushers after prolonged use. During overload conditions, the hydraulic system automatically triggers an alarm to protect core components.
Integrated hydraulic and lubrication station reduces oil consumption by two-thirds. Combining two systems into one saves installation space and significantly simplifies piping. The optimized oil tank requires only one drum of lubricating oil—compared to three drums in traditional equipment—significantly lowering daily production costs. The over-iron protection system, controlled by a hydraulic cylinder, automatically discharges foreign objects and resets, offering greater sensitivity and faster reset times than the mechanical over-iron protection found in spring-loaded cone crushers.
Intelligent control system enables remote monitoring to reduce labor requirements. It monitors parameters such as load, current, and temperature in real time, provides automatic alerts for liner wear and replacement, and supports remote viewing of operating status and historical data via computer or mobile phone, significantly reducing the frequency of on-site inspections and lowering labor costs.
Simple structure, low failure rate. A single hydraulic cylinder integrates three major functions: discharge opening adjustment, over-iron protection, and chamber cleaning. Compared to multi-cylinder models, the structure is more compact with fewer potential failure points, making maintenance convenient and ensuring high production line uptime.
Cone Crusher Application Scenarios
Medium and fine crushing stages in sand and gravel aggregate production lines to produce high-grade construction aggregates; medium and fine crushing processes in the beneficiation of iron ore and metal/non-metal ores; crushing and processing of limestone and basalt in cement plants and the building materials industry; medium and fine crushing and shaping of high-hardness materials such as granite and river pebbles.
Cone Crusher Customized Process Flow
For typical medium and fine crushing operations of ores, we recommend a two-stage closed-circuit process using a jaw crusher and a cone crusher: Raw material is fed into the jaw crusher for primary crushing after de-silting via a vibrating feeder; the primary crushed material is classified by a vibrating screen, with the oversize material entering the DLD single-cylinder hydraulic cone crusher for secondary crushing, where layer-crushing ensures high throughput and excellent particle shape; The cone crusher discharge forms a closed-circuit loop with the screening process; qualified material is sent to storage, while oversized material is returned to the cone crusher for re-crushing. The DLDS medium-crushing model and DLDH fine-crushing model can be flexibly combined based on the target discharge size to achieve step-by-step crushing. The overall capacity ranges from 25 to 2,181 tons per hour, accommodating the needs of production lines of various scales.
Service Scope
Solution Design: Based on material type, hardness, feed size, and target capacity, we provide a two-stage closed-circuit process solution featuring a jaw crusher and cone crusher. We precisely match the DLDS or DLDH model and motor power, and provide foundation installation drawings. Equipment Manufacturing: Manufactured in our own factory, the helical bevel gear drive system and integrated hydraulic lubrication station are precision-machined and assembled in-house, with strict quality control ensuring factory-grade quality. Installation and Commissioning: We dispatch professional engineers to the site to provide guidance on foundation construction, equipment hoisting, commissioning of the hydraulic lubrication system, and trial production with actual feed material, ensuring the production line meets all performance standards and achieves full capacity. Operation and Maintenance Management: We provide regular inspections, supply of wear parts such as liners, remote intelligent diagnostics, and on-site operation and maintenance management services to ensure stable operation throughout the equipment’s entire lifecycle.
Cone Crusher Overseas Project Case Studies
A medium and fine crushing project for an iron ore beneficiation plant in West Africa, with an annual processing capacity of 3 million tons of raw ore. The client is a major local mining enterprise. The ore consists of high-hardness iron ore, which places extremely high demands on the continuous operation rate of the medium and fine crushing equipment and the final product particle size. Our company supplied two DLDS medium-crushing and three DLDH fine-crushing single-cylinder hydraulic cone crushers to form a two-stage closed-circuit crushing process. After commissioning, the medium-crushing units stably produced 800–1,200 t/h, while the fine-crushing output was consistently maintained at 8–15 mm. The laminar crushing process ensured excellent product shape with flake and needle content below 10%, meeting the ideal feed size requirements for the downstream ball mill. The integrated hydraulic lubrication station, designed to reduce oil consumption by two-thirds, performed reliably in Africa’s high-temperature environment. The intelligent control system enabled remote monitoring from the central control room, significantly reducing on-site inspection labor. Customer feedback: The equipment has operated for two years without major failures; liner life and oil consumption far exceeded expectations, and remote monitoring has greatly helped reduce O&M costs at the African mining site.
Technical parameters:
Model
Feed opening size( mm )
Processing capacity( t/h )
DLDS420
250
85～170
DLDS430
360
125～345
DLDS440
450
267～605
DLDS660
560
349～1050
Cone Crusher Frequently Asked Questions
Q: What are the advantages of single-cylinder hydraulic cone crushers over multi-cylinder models in medium and fine crushing of ore?
A: The core advantage of single-cylinder hydraulic cone crushers in medium and fine ore crushing lies in the laminar crushing principle—compared to traditional single-particle compression models, they increase production capacity by 35%–60%, produce high-quality cubic-shaped final products, and have low flaky and needle-like particle content. Compared to multi-cylinder models, they feature a simpler structure, fewer potential failure points, and easier maintenance. A single hydraulic cylinder at the bottom integrates three key functions: discharge opening adjustment, iron protection, and chamber cleaning. The integrated hydraulic and lubrication station saves space and reduces oil consumption by two-thirds.
Q: Do you provide a complete service—from design to installation and commissioning—for cone crusher configurations in aggregate production lines?
A: Yes. Aggregate production line configurations must be tailored to the feed size after primary jaw crushing and the target output requirements. We provide comprehensive design services—precisely matching DLDS medium-crushing or DLDH fine-crushing equipment and determining motor power, complete with foundation installation drawings. After equipment delivery, we dispatch a professional team to complete installation and commissioning until trial production with actual feed meets specifications. If required, we can also provide turnkey EPC services for the entire line, including feeders, jaw crushers, cone crushers, vibrating screens, and belt conveyors, to avoid the coordination hassles of dealing with multiple suppliers.
Q: How do cone crushers perform in overseas mining projects? Is the equipment failure rate high?
A: The DLD series cone crushers have been operating stably in numerous overseas mining projects across West Africa, Southeast Asia, Central Asia, and other regions. Thanks to the use of helical bevel gear drives and oil-sealed wedge bearings, combined with an intelligent control system that monitors operating parameters in real time and provides automatic alerts for liner wear, the equipment has a low overall failure rate and high production line uptime. Our overseas project services cover the entire chain, from equipment export and transportation to on-site installation, remote intelligent operation and maintenance, and the supply of wear parts, ensuring long-term, worry-free production for overseas customers.
Please provide the material type, hardness, feed size, target production capacity, and finished product size requirements, and we will match you with the most suitable model. If you need a complete production line (feeder, jaw crusher, cone crusher, vibrating screen, conveyor belt), we can supply it as a package to avoid dealing with multiple suppliers.
