Product details

The pearl white body is clean and bright, and the XOYI P3K Easy Edition combines flexibility and practicality. Equipped with an 800W/1000W sine wave motor (optional power) and a 60V/52Ah lithium battery (standard 52Ah, optional 70Ah), the economical driving range can reach 110 kilometers per hour. The front and rear disc brakes are sensitive in braking, the aluminum alloy wheels are beautiful and durable, and the one click start combined with the central locking operation is convenient. The steep slope descent improves the safety of downhill driving. Fully enclosed frame panel body, 2 doors and 3 seats, with a turning radius of ≤ 4 meters, making it easy to handle narrow roads and short distance travel in the city.

Model code: P3K

Length x Width x Height (mm): 2770 x 1180 x 1615

Wheelbase (mm): 1065

Front/rear wheelbase (mm): 1950

Minimum ground clearance (full load) (mm): ≥ 160

Minimum turning radius (m): ≤ 4

Curb weight (kg) (excluding battery): 292

Total weight (kg): 362.3

Actual vehicle speed (km/h): 39

Maximum displayed speed (km/h): 51

(0-30km/h) Acceleration time (s): ≤ 12

Maximum climbing gradient (%): ≥ 20

Motor power (kW): 0.8/1.0 kW (800W/1000W optional)

Motor form: sine wave motor

Battery type: 60V/52Ah lithium battery (standard 52Ah, optional 70Ah; optional lead-acid 86Ah)

Charging time (h): 8

Single charge range (km): ≥ 100 (maximum speed)/≥ 110 (economy speed, 25 ℃)

Drive type: rear wheel drive

Transmission ratio (rear axle ratio): 1:9

Body type: Fully enclosed frame panel body

Vehicle structure: 2 doors and 3 seats

Number of car doors: 2

Front suspension: hydraulic front fork

Rear suspension: Trailer arm suspension (composite shock absorber)

Steering method: lever type (mechanical steering)

Tire specifications: Front 4.00-10, Rear 4.50-10

Wheel rim: Aluminum alloy wheel hub (aluminum wheel)

Braking system: front/rear disc, with front/rear disc brakes for service braking

Parking brake type: handlebar+handball type

Minimum ground clearance: ≥ 160 mm

Turning radius: ≤ 4 meters

Top speed: 39 km/h (actual)/51 km/h (displayed on the meter)

Maximum climbing gradient: ≥ 20%

Maximum load capacity: Total weight 362.3kg, curb weight 292kg, load capacity approximately 70.3kg

Seat configuration: driver and driver manual adjustment in both directions, front ordinary seats, colored leather fabric

Internal configuration: front indoor ceiling light, floral leather floor leather, fan sunroof (glass roof), manual window lift, central locking, one touch start (non integrated), LED module instrument panel with reverse image, hill descent control, manual, maintenance manual

External configuration: tail wing, white glass door glass, black door handle, LED front combination light, rear fog light, reversing light, built-in antenna, boneless wiper, rear window glass opening

Interior color: gray white set of Mal é green (optional)

Available body colors: pearl white, European style blue with pearl white, tender yellow with bean sprout green, tea green with beige
