HDP50 In-line high density d sub connector product introduction:

The HDP50 straight-socket high density connector belongs to the D-SUB high-dense (HD-20) series. It is designed for three rows of 50 needle straight-socket PCBs. It has small volume, multi-channel, high reliability and welding-free efficient installation, and is the best choice for industrial equipment miniaturization and high dethality signal interconnection.

The core specification and configuration of this d connector

Pin Configuration: Three rows of 50 pins (2.77 mm spacing), standard D-shielded housing, in-line (vertical) PCB mounting, suitable for board-to-board / board-to-wire high-density connections.

Termination mode: In-line (THT), male pin directly inserted into the PCB, no wire / crimp, high efficiency of batch assembly; Positioning columns guard against decay to ensure precision of positioning.

Enclosure and insulation: metal shielded enclosure (tinted), strong resistance to interference; Base is glass fiber reinforced nylon (UL94V-0), high temperature resistance, flame retardant, good insulation.

Contact parts: high-purity copper alloy, gilded nickel substrate, low contact resistance, oxidation resistance, and plug resistance.

Key performance parameters of 50 Pin D Connector Male

Electrical performance: frontal and static current 3 A / pin; 1250 Vac / 1min;Extreme resistance ≥ 5000 MΩ; Contact resistance ≤ 7mΩ.

Mechanical performance: Insert ≥ 500 times;Metal enclosure shield; Straight socket, shock proof and pine proof.

Environmental performance: operating temperature - 55 ° C ~ 105 ° C;Moisture and dust protection are suitable for the harsh industrial conditions.

Compliance: RoHS, UL94V-0, environmental protection and safety.

Typical application scenarios of Dp 50 Pin D Connector

Industrial control: PLC, servo drive, industrial control machine, IO module high density signal interconnection.

Communication equipment: gateway, base station, data terminal multi-channel data / control signal transmission.

Instrumentation: High-speed signal connections inside medical equipment, test and measurement instruments.

CNC and automation: CNC machine tools, robots, and control interfaces for automated production lines.

Railway / vehicular: On-board industrial control and railway signal equipment are stablely interconnected.

Dp 50 Pin D Connector Electrical Performance:

Rated Current (Pin): 5A

Rated Current (Socket): 5A

Contact Resistance: 25 mΩ MAX

Insulation Resistance: 1000 MΩ MIN

Dielectric Withstanding Voltage: 1000 VRMS

Operating Temperature: -55°C ~ 125°C
