| HOUSING | PBT, UL94V-0, WHITE |
| SHELL: | COOPER ALLOY, NI 30U' MIN OVERALL |
| CONTACT: | COPPER ALLOY, G/F GOLD PLATED ON THE CONTACT AREA, 100-200U' SN PLATED ON SOLDER TAILS, BOTH NI 30U' MIN UNDER PLATING OVER ALL |
| ELECTRICAL CHARACTERISTICS: | |
| CURUENT RATING: | 1.5AMP |
| VOLTAGE RATING: | 30V (RMS) MAX |
| CONTACT RESISTANCE: | 30mΩ MAX |
| INSULATION RESISTANCE: | 100mΩ MIN AT 500V DC |
| DIELECTRIC WITHSTANDING VOLTAGE: | 500V AC RMS |
| OPERATING TEMPERATURE: | 0℃~+50℃ |
| INSERTION FORCE : | 3.5KG MAX |
| WITHDRAWAL FORCE : | 1.0KG MIN |
