| HOUSING: | HIGH TEMP THFRMOPLASTIC BLACK |
| TIP SPRING: | COPPER ALLOY T=0.25, G/F ON CONTACT AREA, 120U'' SN ON SOLDER TALL, ALL OVER NI 50U'' MIN |
| SHUNT TERMINAL: | BRASS STRIP T=0.3, G/F ON CONTACT AREA, 120U'' SN ON SOLDER TALL, ALL OVER NI 50U'' MIN |
| PIN: | BRASS, G/F OVER NI 50U'' |
| SHELL: | BRASS, T=0.30mm, PLATING 50U'' NI |
| TERMINAL: | STAINLESS STEEL T=0.3 |
| RATING CURRENT: | DC 20V 10A |
| CONTCAT RESISTANCE: | 30mΩ MAX (INITIAL) |
| DIELECTRIC WITHSTANDING VOLTAGE: | 500V AC FOR ONE MINUTE |
| INSULATON RESISTANCE: | 100mΩ MIN MEASURED BY 500 V DC |
| INSERTION FORCE : | 3.0KGF MAX |
| WITHDRAWAL FORCE: | 0.3~3.0 KGF |
| LIFE TEST: | 5000 CYCLES MIN |
If you are interested in the product, contact 2bvideo.com for more information for more information
The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.
Main Product:
Type-C connector,
USB connector ,
DC Jack connector,
AUDIO JACK connector,
DP connector,
HDMI connector
