Product details

Full automatic hot foil stamping machine for gift box

The flatbed automatic hot foil stamping machine is a high-precision, high-stability post-press solution designed for the modern paper printing and packaging industry. Featuring a planar-to-planar vertical pressing structure, it uses advanced heat transfer technology to apply electroplated aluminum foil, laser foil, holographic anti-counterfeiting foil, and other specialty materials onto sheet-fed substrates. This automatic hot stamping equipment supports multiple finishing processes in a single system, including hot stamping, foil stamping (gold/silver), embossing, and die-cutting—making it ideal for high-end packaging production.

Automatic flatbed sheet-fed hot stamping Machine//Technical Parameters

Model	H-TC4060ARS	H-TC5070ARS
Size of Hot Plate(mm)	400×600	500×700
Work Table Size(mm)	600×800	700×900
Max. Pressure(kg) Max. Head Stroke(mm) Heater Capacity(KW)	10000 100 15	10000 100 20
Max stamping speed Temperature adjustment Temperature control accurate	2000pcs/H 0-300℃ +/-1	2000pcs/H 0-300℃ T+/-1
Stamping accurate Gross weight (Kg) Package(mm)	+/- 0.05-0.15mm 4000 kg 4800×1800×2000	+/- 0.05-0.15mm 6000 kg 4800×1800×2000
Works supply	3 phase 380V	3 phase 380V

Automatic flatbed sheet-fed hot stamping Machine //Advantage Key Features • Fully Automated Operation Equipped with a paper stacking table, suction feeder, automatic foil feeding and unloading system, and high-stack delivery unit, ensuring continuous and efficient production. • High-Precision Positioning System Combines front and side guides with optional CCD vision alignment for accurate registration, even on complex designs. • Advanced Servo Control System Servo-driven foil feeding and stamping ensure stable pressure, precise control, and consistent stamping quality. • Multi-Zone Temperature Control Independent heating zones provide uniform temperature distribution, improving foil adhesion and finish quality. • Reliable Feeding System Vacuum suction feeding with double-sheet detection prevents misfeeds and ensures smooth operation. Material Compatibility Suitable for a wide range of substrates, including: • Cardstock and coated paper • Specialty papers • Paper weights from 80g to 1200g Applications Widely used for premium paper product finishing, such as: • Cigarette and alcohol packaging boxes • Cosmetic packaging boxes • Luxury gift boxes • Hardcover book covers • Greeting cards • Labels and tags

Automatic intelligent hot foil stamping machine for paper package

Performance Highlights

• Precision Registration Technology

Advanced positioning using front/side lays combined with optional CCD vision alignment ensures exact image placement, even for intricate patterns and multi-process jobs.

• Servo-Driven Foil Control

High-response servo motors regulate foil feeding and stamping actions, reducing waste while improving repeatability and consistency.

• Uniform Thermal Management

Multi-zone heating system maintains stable temperatures across the stamping area, enhancing adhesion and surface finish quality.

• Smart Feeding & Safety Detection

Vacuum feeder with double-sheet and misfeed detection minimizes downtime and protects materials during high-speed operation.

• Integrated Automation Workflow

From sheet feeding to foil transfer and final delivery, the entire process is automated to reduce labor costs and increase productivity.

Material Range/Compatible with various paper types, including coated board, art paper, and specialty substrates, with thickness ranging from 80gsm to 1200gsm.

Industry Applications/

Ideal for high-value printed products requiring decorative and anti-counterfeiting finishes:

• Luxury packaging for cosmetics and spirits

• Premium cigarette and consumer goods boxes

• Gift packaging and rigid box surfaces

• Book covers and stationery products

• Labels, cards, and branded paper items
