The Vertical Rotary Automatic Screen Printing Machine is a high-performance solution for fully automated screen printing on cylindrical and specially shaped products. Designed for high-volume production, this automatic screen printing machine integrates automatic feeding, flame treatment, a 12-station vertical rotary turntable, servo screen printing, UV LED curing, and automatic unloading into one efficient production system. Products are automatically loaded and accurately positioned on the 12-station rotary table, ensuring stable indexing and consistent printing results. The integrated flame treatment system improves ink adhesion on low-surface-energy materials such as PP and PE, while the servo-driven screen printing system provides precise control of printing speed, stroke, and pressure for high-quality, repeatable printing. After printing, the UV LED curing system rapidly cures the ink to improve production efficiency, print durability, and surface quality. Finally, the automatic unloading mechanism transfers finished products out of the machine, significantly reducing manual labor and enabling continuous production. With its compact vertical rotary design, precise servo control, and integrated automation, this vertical rotary screen printing machine is an ideal choice for manufacturers seeking efficient, stable, and high-precision printing for cylindrical plastic products, cosmetic containers, beverage cups, bottles, and other industrial components.

444

Bottle caps Automatic screen printing machine// character

In the cosmetics and washing industry, the caps is used widely, the cap is produced by manufacturer, and then we decorate is by a variety of methods.

We usually us flexographic printing machine to print the top of the caps, and automatic screen printer is the better choice for decorating the side of the caps. Since the cap production is relatively larger, full automatic curved screen printing machine has become an important option. Monochrome automatic screen printing machine for bottle caps to complete the monochrome silk screen.

Automatic feeding, to ensure the correct delivery of the cap;
Using flame treatment device to ensure the adhesion of PP PE material;
UV curing unit , UV ink can be used for instantaneous drying;
You can replace the different fixtures, to achieve a different cap silk screen.

Parameter

Printing Max. Diameter ￠10-￠70mm;
Printing Max Length 20-200mm;
Printing station 12;
Printing Speed 3600Pcs/H;
Power supply 380V 50 MHz;
Air pressure 0.6-0.8Mpa;
Total power 4.5KW
Package Dimension: (Mainframe) 2.06×1.70×1.93m;
Gross weight: 1100Kg

Bottle-cap automatic screen printing machine advantage

Integrated feeding system with flexible width and stepless speed adjustment matches transport speed with printing speed.
Automatic manipulator feeding ensures smooth production flow.
Flame or plasma treatment improves PE cup surface adhesion for lasting prints.
Vertical turntable transmission provides stable, high-precision operation.
Screen printing fixtures are adjustable, and electronic sensors prevent missing prints. Optional photoelectric tracking supports multi-color designs.
High-performance UVLED curing enables instant ink drying, energy-saving and eco-friendly.
Touch screen controls and mechanical transmission make operation simple and intuitive.
CNC-machined components ensure high-speed stability up to 2,000 cups/hour. German and Japanese electrical systems guarantee reliable printing quality.

Main configuration

Main Motor:BGM Motor/reduver;
Feeding Motor:STS Motor-31K15RGN-C/15W;
Sensor:DZ47LE-32;
SWTICH):Schneider -France;
Contactor:Schneider -France;
Relay : Idec-Jappan;
IR drying ):Taiwan;

Transport speeder :STS/AUS22-15W;
Collecting Motor : STS/51K60RGN-CF/60W;
Drying speeder: STS/AUS22-60;
Temperature controller: RKC/REX-C100;
Counter: DHC;
Transducer: TAIAN/N2-2P5H;
Cooling fan: SUNON/DP200A.
