Screen Printing Machine Oblique Arm Screen Printer High-Speed Screen Printing and UV Curing Production Line
KC Printing Machine (Group) Limited
10 year year
Product details

Slant-arm silk screen printing machine with UV curing system

           UV screen printing for paper decoration has evolved from conventional semi-automatic processes toward integrated and highly automated production systems. However, a fully automatic paper screen printing line can require significant capital investment, making it less suitable for small and medium-sized manufacturers. To provide a more practical and cost-effective screen printing and UV production line, this system combines a semi-automatic oblique arm screen printing machine, a UV curing machine, and an automatic robotic transfer system. The robot transfers printed sheets from the oblique arm screen printer to the UV curing unit automatically, creating a continuous screen printing and UV curing workflow with an output of approximately 1,200–1,500 sheets per hour while reducing manual handling and labor requirements. This integrated screen printing and UV curing production line provides an effective balance between automation, productivity, and equipment investment, making it an attractive solution for small and medium-sized printing manufacturers. It is widely suitable for paper packaging, water transfer paper, heat transfer paper, premium gift boxes, and other paper products requiring UV finishing, providing a flexible and economical alternative to a fully automatic UV screen printing production line.
Printed samples of Cost-Effective Screen Printing and UV Curing Production Line

Slant-arm silk screen printing machine//Parameters

Technical parameters

S-JY6090PV

 S-JY70100PV
1.Max printing thickness:0-40 MM;
2.Power Pressure:4-6 kgf/cm2;
3.Net weight: 560 KG;
4.Max printing area:600×900 MM;
5.Max printing speed:1000 Pcs/H.
6.Max screen frame size: 900×1200 mm;
7. Table adjustment Longitude: +-0.1 mm;
8. Working table size: 700×1000 mm		 1.Max printing thickness:0-40 MM;
2.Power Pressure:4-6 kgf/cm2;
3.Net weight: 65 0KG;
4.Max printing area:700×1000 MM;
5.Max printing speed:1000 Pcs/H.
6.Max screen frame size: 1000×1300 mm;
7. Table adjustment Longitude: +-0.1 mm;
8. Working table size: 800×1100 mm

Factory
  • 110 V-220 V Power supply;
  • 5-7 Bar compress air;


Flat UV Drying Machine//Parameter

Technical parameters

M-50250UVC

M-80250UVC
  • Conveyer width:500mm;
  • Total wattage:9KW;
  • Wind fan wattage:200W/380V;
  • Conveyer motor wattage:1000W/1P/380V;
  • ConveyEr speed:0~10m/min;
  • Speed adjustment:Stepless;
  • Lamp wattage:5.6KW/380V×2pcs;
  • Max height of production: 80mm.
  • Entrance Length: 650mm.
  • Drying length: 1200mm.
  • Max curing Objects:800×60mm(W×H);
  • Total Wattage:9KW;
  • Fan Motor Wattage:1000W/380V;
  • Transport Motor wattage:1000W/1P/380V;
  • Conveyer speed:0~10m/min;
  • Speed adjustment mode:stepless;
  • Lamp wattage:5.6KW/380V×2pcs.;
  • Max objects height: 80mm

Works supply
  • Power: 3 phase 380V.

Package list

Outer Dimension: 2.500×0.560×1.370m;

Net weight: 296KG



Package Dimension: 2.58×0.85×1.35m;

Gross weight: 379KG; CBM:3.364945

Package Dimension: 2.670×1.10×1.420m;

Gross weight: 395KG; CBM:4.17054

Machine structure

Cost-Effective Screen Printing and UV Curing Production Line

Paper packaging partial UV screen printing production line

  • The structure adopts a swing arm structure;
  • The workbench has up and down, left and right, front and back fine-tuning devices;
  • The printing drive uses a motor drive, and the lifting of the inclined arm is driven by a motor, which can be frequency-controlled.
Unloading robot--
  • Automatically complete the grabbing and placement of materials;
  • Accurately adjust the unloading position and angle to ensure the accurate placement of materials and improve the accuracy and consistency of production.
  • It has the characteristics of stable structure and high reliability. It ensures stable operation through various components and can be used for unloading of various dangerous objects.
UV curing machine
  • The paper removed from the screen printer by the robot is UV-cured.
  • It has the characteristics of instant drying, which can greatly shorten the coating process time and improve production efficiency.
  • It can make the printed surface achieve high gloss, friction resistance and solvent resistance.
Integrated paper packaging partial UV screen printing production line
  • It integrates oblique arm flat screen printer, feeding manipulator, UV light curing machine and other equipment to realize the automated production of partial UV screen printing of paper packaging.
  • High production efficiency, various equipment work together to quickly complete the printing, feeding and curing of paper packaging, improve production efficiency and product quality.
  • Good printing quality, through precise positioning and control, to ensure that the pattern of partial UV screen printing is clear, accurate and colorful.
  • Save labor costs, reduce manual operation links, and reduce labor intensity and labor costs.
Contact Now

If you are interested in the product, contact 2bvideo.com for more information for more information

To:
KC Printing Machine (Group) Limited
