Bc6050 High Quality Shaping Machine for Metal
Products Description:
Shaper Machine ram could be straight reciprocating motion ,and the Tool rest could rotary to multiple angle in the vertical plan . Also could manual feeding .the workbench takes along the workpieces making the intermittent horizontalorverticalfeedmovement . The machine could process plan, groove, dovetail surface ,also could process the forming surface ,and also could cut the workpieces fixed on workbench by the reciprocating motion tool rest .
Technical Parameter:
|
Model |
BC6050 BC6066 |
||
|
Max .shapping length(mm) |
500 |
660 |
|
|
Max. range of the horizontal movement of the table(mm) |
525 |
660 |
|
|
Max. distance between the ram bottom and table(mm) |
370 |
380 |
|
|
Max. length of the vertical movement of table(mm) |
270 |
315 |
|
|
Dimensions of table top(L×W)(mm) |
440×360 |
660×400 |
|
|
Max. stroke length of the tool head(mm) |
120 |
120 |
|
|
Max. swivel angle of the tool head(°) |
±60° |
±60° |
|
|
Max. section of tool(W×T)(mm) |
20×30 |
20×30 |
|
|
Number of ram reciprocation per minute(NO/min) |
14-80 |
14-80 |
|
|
Range of table feed |
Horizontal |
0.2-0.25 0.08-1 |
0.2-0.25 0.08-1 |
|
Vertical(mm/rpm) |
|||
|
Speed of rapid travel of table |
Horizontal |
0.95 0.38 |
0.95 0.38 |
|
Vertical |
|||
|
width of the T-slot for center positioning(mm) |
18 |
18 |
|
|
Power of the main motor(k w) |
3 |
3 |
|
|
N.W/G.W(kg) |
1650 |
2200 |
|
|
Overall dimensions(L×W×H)(mm) |
2160×1070×1194 |
2382×1210×1504 |
|
