Product details

Stainless Steel Hot Pepper Grinding Machine

Stainless Steel Hot Pepper Grinding Machine Features

1. Superfine Grinding Machine is Hot Pepper Grinder

2. Maxhine materials of Superfine Grinding Machine :AISISUS304, AISISUS316L, and other material.

3. Stainless Steel Hot Pepper Grinding Machine is Superfine Grinding Machine

Hot Pepper Grinder Machine Main Application

Comprised of main frame, auxiliary machine and electrical control cabinet, this Hot Pepper Mill Machine has such performances as winnowing, screen or mesh free, uniform size and continuous operation, and has reached the international advanced level, thus being widely used for material crushing in pharmaceutical, chemical and foodstuff trades etc..

Hot Pepper Mill Working Principle

The material is fed into the crushing chamber by a screw conveyor, cut and crushed by high speed rotating blade and conveyed to the cyclone separator by means of negative pressure air conveyance before being discharged by bag type collector, and the dust is filtered and recovered by dust collector through filter barrel having no dust flying during production, it can improve utilization rate of the material and reduce the cost of enterprise

Model	capacity	Size of input materials	Size of output materials	Motor power	Speed	Overall dimension	Weight
WF-15	20-200kg/h	<10mm	80-1000mesh	13.5kw	~5800rpm	420012002700mm	1100kg
WF-18	30-450kg/h	<10mm	80-1000mesh	19.8kw	~5800rpm	450012002700mm	1300kg
WF-30	50-750kg/h	<10mm	80-1000mesh	46kw	~5800rpm	640013003960mm	1800kg
WF-60	80-1000kg/h	<10mm	80-1000mesh	84.15kw	~5800rpm	750023004200mm	3200kg
WF-80	100-1300kg/h	<10mm	80-1000mesh	90.17kw	1400r/min	750025004200mm	4000kg
