Pillow Type Packing Machine For Aluminum

The aluminum pillow shrink packing machine is an automated packaging device specifically designed for long, strip-shaped aluminum profiles. It achieves efficient, standardized packaging through continuous film forming, heat sealing, and cutting processes.

MAIN PERFORMANCE

Suitable for packaging hardware items of varying lengths, such as: long aluminum profiles, stainless steel pipes, hinge packaging, door and window hardware, and hand tools.
Three-servo automatic sensing system for bag length recognition and fixed-length mode.
7-inch touchscreen interface for intuitive operation and easy maintenance.

USE RANGE

1. Widely used in packing production line for aluminum profile for flow packaging across industries such as hardware, food, daily chemicals, and pharmaceuticals.

2. Hardware: Guide rail packaging, hardware tools, aluminum profiles (1-10 meters), pipe packaging, etc. Automatically senses bag length based on product dimensions.

PROFILE PACKING PROCESS

MAIN TECHNICAL PARAMETERS AND REQUIREMENTS

Film Width 　Max. 250mm
Bag Length 　45–190mm or 120–280mm
Bag Width 　30–110mm
Product Height 　Max. 45mm
Film Roll Diameter 　Max. 320mm
Packaging Speed 　40–230 packs/min
Power Specifications 　220V, 50/60Hz, 2.4KVA
Machine Dimensions 　L 3920 × W 670 × H 1320
Machine Weight 　500Kg

COMMON FAULTS AND SOLUTIONS

1. Poor Sealing or Burning

Cause: Improper temperature setting (PE film recommended 120-180°C), insufficient pressure, or too short sealing time.
Solution: Gradually adjust temperature (5-10°C increments), inspect heating elements for wear, increase spring pressure.

2.Film wrinkling or misalignment

Cause: Uneven tension, misaligned guide rollers, or improper roll installation.
Solution: Recalibrate tension control system, adjust guide roller angles, ensure roll center aligns with machine axis.

3.Blade fails to cut or cuts unevenly

Cause: Blade wear, motor failure, or loose drive chain.
Solution: Replace blades with imported materials ,check motor belt tension, clean accumulated dust from chain.
