LCP Glass Filled SMT CR1632 Coin Cell Holder

LCP Glass Filled SMT CR1632 Coin Cell Holder

2 week ago

0 0

HuiZhou Antenk Electronics Co., LTD

 5 year year

Product details

Huizhou Antenk Electronics Co., Ltd. manufactures BT-M-G0-R-CR1632A polarized SMT coin cell holder engineered to secure CR1632 coin batteries and build stable polarized conductive circuits on PCBs. This holder adopts glass filled LCP UL94V0 flame retardant plastic as insulating base, matched with 0.15mm thick phosphor bronze contact terminals finished with 30 micro inch nickel underlayer and standard 1 micro inch gold flash plating, and customers can upgrade to various gold thickness options from 3 micro inch up to 30 micro inch gold to enhance anti oxidation performance and low consistent contact resistance in humid and high temperature working environments. It is M-type SMT surface mount structure with dedicated polarized PCB layout marks, supporting tray packing and tape reel packing two packaging modes to satisfy manual assembly and high speed automatic SMT mass production lines. This polarized coin cell holder is widely deployed in digital cameras communication devices industrial control sensors smart home appliances electronic toys and precision measuring instruments. Operators must align positive and negative polarity marks strictly with PCB layout during reflow soldering, avoid excessive bending force to prevent permanent phosphor bronze spring deformation and store finished holders in dry warehouse to protect nickel gold plating layers from corrosion. Unlike competitors outsourcing stamping and plastic injection molding Antenk implements full in house production process including independent precision mold development phosphor bronze high speed stamping LCP injection molding nickel gold electroplating and complete laboratory electrical and dimensional reliability testing, holding ISO9001 ISO14001 IATF16949 and UL E472792 certifications while fully complying with RoHS HSF and REACH environmental standards. We own hundreds of self developed plastic and metal precision molds, provide customizable plating and packaging solutions, offer round the clock professional technical support, and more than seventy percent of our coin cell holders are exported globally backed by our Guangdong Famous Trademark ANTENK and steady uniform batch manufacturing quality.

UL94V0 Glass Filled LCP Housing delivers high heat resistance and stable structural rigidity to resist deformation during SMT reflow soldering processes.

0.15mm Thin Phosphor Bronze Contact maintains balanced elastic clamping force for long-term tight contact with CR1632 coin cell electrodes.

1u Gold Flash Nickel Plated Terminal combines nickel barrier and thin gold flash coating to reduce contact resistance and prevent surface oxidation effectively.

1. Material & Plating Specifications

1.1 Base housing material: LCP 30% glass filled plastic, UL94V-0 flame retardant grade

1.2 Contact raw material: 0.15mm thick phosphor bronze

1.3 Standard plating: 30 micro inch nickel base + 1 micro inch gold flash

1.4 Optional plating grades: 3μ",5μ",10μ",15μ",30μ" gold plating

2. Product Type & Compatible Battery

2.1 Mounting form: M = SMT surface mount type

2.2 Design feature: Polarity marked positive/negative polarized structure

2.3 Matching battery: CR1632A coin cell

3. Dimension & Tolerance Standard (Unit: mm)

3.1 PCB layout overall dimensions: 29.00±0.05, 23.20±0.05, 28.68, 25.15, 17.20, 16.00, 5.38, 4.00±0.05, 3.50±0.12

3.2 Circular chamber sizes: Φ16.26, Φ6.10; Contact chamber: 6.35×3.00

3.3 Precision tolerance rule: All labeled dimensions adopt ±0.05 / ±0.12 tolerance as marked on drawing

4. Order Code Definition & Packaging Options

4.1 Code breakdown: BT=Coin Cell Holders, M=SMT TYPE, G0=Gold flash plating, R=Tape & reel packing, CR1632A=product model

4.2 Two available packing methods

4.2.1 A: Tray Packing

4.2.2 R: Tape & Reel Packing

5. Environmental Compliance

5.1 Fully comply with Pb-free, RoHS and HSF standards

6. Application Scenarios

6.1 Digital cameras

6.2 Communication equipment

6.3 Industrial control sensors

6.4 Smart home appliances

6.5 Electronic toys

6.6 Precision measuring instruments

7. Usage Precautions

7.1 Align positive and negative polarity labels strictly with official PCB layout during reflow soldering

7.2 Avoid over-bending contact springs to prevent permanent elastic deformation of phosphor bronze terminals

7.3 Store finished holders in dry warehouse environment to prevent corrosion of nickel and gold plating layers

7.4 Only install standard CR1632A coin cells to guarantee stable polarized conductive performance
