High Pressure CTS Heavy Duty Gantry Machining Center - Ultimate Heavy-Cut Precision & Efficient Chip Control
For heavy-duty industrial machining scenarios involving large workpieces, tough alloy materials, and continuous high-load cutting, the High Pressure CTS Heavy Duty Gantry Machining Center stands as a reliable high-performance solution. Built with ultra-rigid gantry frame structure and optimized industrial-grade transmission systems, this machining center delivers stable, high-precision, and high-efficiency processing for aerospace parts, heavy machinery components, large molds, and engineering structural parts. Its core customized cooling and chip management system completely solves the pain points of high-temperature tool wear, sticky chips, unsmooth chip discharge and reduced machining accuracy in heavy cutting operations.
At the core of its superior processing performance lies the professionalHigh-Pressure Coolant System, the powerhouse that supports full-cycle high-quality machining. This high-pressure integrated coolant system features adjustable high-pressure output, precise flow control and full-machine circulation cooling design, which can continuously deliver high-pressure coolant to the cutting area. It perfectly matches the extreme working conditions of deep hole drilling, heavy milling and long-time continuous machining, providing stable power support for subsequent tool cooling and chip management procedures.
To achieve zero-deviation Tool Cooling in heavy cutting, the equipment is fully equipped with Through-Spindle Coolant and Through-Coolant Tool configurations. The Through-Spindle Coolant design realizes straight-through high-pressure coolant delivery from the spindle core to the tool tip, avoiding the problems of scattered coolant and ineffective cooling of traditional external spraying. Paired with professional Through-Coolant Tool with internal cooling channels, it enables omnidirectional and in-place cooling of the tool’s cutting edge, friction surface and heat concentration area. This thorough cooling method rapidly takes away massive cutting heat generated by heavy-load machining, effectively restrains tool thermal deformation and wear, greatly extends tool service life, and maintains consistent machining precision for a long time.
Cooperating with the high-pressure cooling system, the built-in High-Pressure Flushing function realizes all-round cleaning and pressure-assisted chip treatment in the machining area. The high-speed high-pressure coolant flow forms a strong impact force, which can quickly flush the cutting groove, spindle working area and workpiece surface, thoroughly clean residual cutting fluid, fine metal powder and accumulated chips. It eliminates the machining defects caused by chip adhesion and coolant accumulation, keeping the machining environment clean and tidy at all times, and laying a foundation for efficient chip disposal.
Excellent Chip Removal & Chip Breaking capability is another core advantage of this heavy-duty gantry machining center. Benefiting from the super high pressure output of the High-Pressure Coolant System and the directional impact of High-Pressure Flushing, the equipment can effectively break continuous long chips generated from processing ductile materials such as stainless steel, aluminum alloy and alloy steel, avoiding chip winding on tools and workpieces. Meanwhile, the targeted flushing power cooperates with the professional chip removal structure to quickly discharge broken fine chips and bulk chips out of the machining area, realizing integrated automation of chip breaking and chip removal. It effectively solves the industry problems of difficult chip discharge in deep cavity and deep hole machining, low efficiency of manual chip cleaning, and easy scratch of workpiece surface.
In terms of overall operational value, the perfect combination of Through-Spindle Coolant, Through-Coolant Tool and High-Pressure Coolant System builds a closed-loop efficient cooling and chip management system for the equipment. It not only optimizes Tool Cooling effect and realizes efficient Chip Removal & Chip Breaking, but also improves the overall stability and continuity of heavy-duty machining. The equipment reduces tool replacement frequency and manual maintenance costs, shortens production cycle, and ensures high-precision and high-efficiency batch production of large and heavy workpieces.
Rigorous structure, powerful power, and intelligent cooling and chip control — the High Pressure CTS Heavy Duty Gantry Machining Center redefines the new standard of heavy-duty gantry machining, bringing stable, efficient and low-consumption processing solutions for high-end precision manufacturing industries.
| Specification |
JY-C70 |
JY-C100 |
HY-C150 |
| Applicable Series |
TD-S70 |
TD-S100 |
TD-S150 |
| Motor Power |
2.2 kW |
3 kW |
4 kW |
| Weight |
85 kg |
105 kg |
120 kg |
| Dimensions (L×W×H) |
785 × 390 × 530 mm |
860 × 450 × 660 mm |
900 × 500 × 700 mm |
| Outlet Pressure |
70–90 kg (Adjustable) |
70–90 kg (Adjustable) |
70–90 kg (Adjustable) |
| Pump Form |
Vane / Plunger Pump (Optional) |
Vane / Plunger Pump (Optional) |
Vane / Plunger Pump (Optional) |
